AC Infinity 115W Ionboard S22 Full Spectrum Samsung LM301H LED Grow Light
AC Infinity 115W Ionboard S22 Full Spectrum Samsung LM301H LED Grow Light
AC Infinity 115W Ionboard S22 Full Spectrum Samsung LM301H LED Grow Light
Roll over image to zoom in Click on image to zoom
LED Grow Light AC Infinity S22 Main
LED Grow Light AC Infinity S22 Control
LED Grow Light AC Infinity S22 PPFD
LED Grow Light AC Infinity S22 Tent
AC Infinity 115W Ionboard S22 Full Spectrum Samsung LM301H LED Grow Light
AC Infinity 115W Ionboard S22 Full Spectrum Samsung LM301H LED Grow Light
AC Infinity 115W Ionboard S22 Full Spectrum Samsung LM301H LED Grow Light

AC Infinity 115W Ionboard S22 Full Spectrum Samsung LM301H LED Grow Light

Rock Bottom Price
This item is heavily discounted and may not qualify for discounts unless bulk quantities are requested. Request Bulk Discount
AC InfinitySKU: DS-AC-IBS22


Price:
$119
  • Description

Description

The IONBOARD S22 is a high-performance 115W LED grow light engineered to maximize plant yields within a 2x2 ft. grow space. Utilizing premium Samsung LM301H diodes, it provides a full-spectrum output that includes 660nm deep red and 730nm far-red wavelengths, ensuring optimal growth from germination through flowering. Its algorithmically positioned diodes eliminate hot spots, delivering a uniform PAR map that ensures even light distribution across the entire canopy.

Key Performance Highlights

  • Samsung LM301H Diodes: Powered by industry-leading horticulture LEDs for superior efficiency and light intensity.

  • Optimized Full Spectrum: Includes 3000K, 6500K, 660nm, and 730nm wavelengths to support all stages of plant development.

  • Uniform PAR Map: Algorithmically spaced diodes ensure consistent light penetration and prevent central hot spots.

  • Smart Controller Integration: Features a UIS port for connection to smart controllers, enabling app control and automated grow cycles.

  • Precision Dimming: A proprietary driver allows for 0-100% brightness adjustment to suit different growth phases.

  • Passive Cooling Design: The unibody aluminum construction provides silent, fanless heat dissipation for a longer diode lifespan.

  • Environmentally Sealed: IP-65 rated protection ensures the light remains operational in humid and dusty grow tent conditions.



Designed for durability and smart integration, the fixture features a fanless, unibody aluminum board that effectively dissipates heat without the noise of moving parts. It is IP-65 rated to withstand the high humidity and temperatures common in indoor grow environments. As part of the UIS ecosystem, the IONBOARD S22 can connect to smart controllers for advanced scheduling and remote app-based climate management, making it a future-ready solution for both hobbyist and professional growers.

Product Specifications

  • Model: IONBOARD S22 (AC-IBS22)

  • Coverage: 2 x 2 ft.

  • Wattage: 115 Watts

  • Efficiency: 2.7 µmol/j

  • Max PPFD: 1098 µmol/m²/s

  • Diode Count: 272 Samsung LM301H Chips

  • Board Dimensions: 11.81 x 11.81 x 0.43 in.

  • Voltage: 100-277V AC

  • Operating Temp: 32 to 140°F

  • Lifespan: 50,000 Hours

  • Certification: ETL Certified

  • ETL Cert. (Whole Product): PDF

  • Product Manual: PDF
